Network: Global | Grenoble | Lille | Luxembourg | Lyon | Nancy | Nantes | Rennes | Sophia | Strasbourg | Toulouse
IP networks in use
You have to use a public network range to run an experiment between several Grid5000 sites.
Public Networks
- computing : 172.16.112.0/20
- virtual : 10.160.0.0/14
Local Networks
- admin : 172.17.112.0/20
VLANs
- 13: CICT Network
- 100: Production Network
- 101: Admin Network (BMC/eth1)
- 550: RENATER 5
- 667: DMZ-private-Grid5000
Network
Production Network
Physical link details
- Internal links are 1GB ethernet.
- Renater link and the interconnexion between routers R4 and catalyst6500 (GW) are 10GB optical fiber.
| Te1/1 | Te1/2 | Gi3/36 | Gi3/37 | Gi3/38 | Gi3/39 | Gi3/40 | Gi3/45 | Gi3/46 | Gi3/47 | Gi3/48 |
|---|---|---|---|---|---|---|---|---|---|---|
| RENATER | Interco R4-GW | CICT | spastel1-ipmi | g5kservices1-eth1 | g5kservices2-eth1 | g5kservices3-eth1 | g5kservices2-eth0 | g5kservices3-eth0 | g5kservices1-eth0 | nfs-g5k |
| Gi3/41 | Gi3/42 | Gi3/43 | ||||||||
| g5kservices1-bmc | g5kservices2-bmc | g5kservices3-bmc |
